PMC11-AA1V1FJVXJJ ENDRESS+HAUSER Pressure Temperature Transmitter 0 To 20VAC
PMC11-AA1V1FJVXJJ Description
The PMC11-AA1V1FJVXJJ is an economical, compact gauge pressure transmitter from Endress+Hauser’s Cerabar series, designed for reliable pressure measurement of gases, liquids, and steam in standard industrial processes. It features a capacitive, oil-free ceramic diaphragm sensor (99.9% Al₂O₃) for high stability and resistance to wear and corrosion. This cost-effective unit offers a balance of performance and affordability, making it ideal for general process monitoring applications.
PMC11-AA1V1FJVXJJ Key Features
- Oil-free ceramic capacitive sensor: No risk of oil contamination, excellent wear resistance, and long-term stability
- High measurement accuracy: ±0.5% of full scale (URL)
- Excellent long-term stability: 0.2% URL per year
- Compact, lightweight design: Easy installation in confined spaces
- User-adjustable measuring range: Flexible configuration for diverse applications
- Wide process and ambient temperature tolerance
- Robust construction: Resistant to vibration and industrial contaminants
- Standard threaded process connections: ISO 228, ASME, DIN 13 compatible
- Cost-effective solution: Ideal for standard industrial pressure monitoring
PMC11-AA1V1FJVXJJ Materials & Applications
Materials
- Sensor Diaphragm: 99.9% high-purity alumina (Al₂O₃) ceramic
- Process Connection & Wetted Parts: 316L stainless steel
- Housing: High-grade industrial aluminum alloy
- Seals: High-performance elastomers (FKM/EPDM)
- Electronics: Conformal-coated circuit boards for environmental protection
Typical Applications
- General industrial process pressure monitoring
- Water treatment and wastewater systems
- HVAC and building automation
- Pump and compressor pressure control
- Filter and pipeline pressure monitoring
- Food and beverage processing
- Pharmaceutical manufacturing
- Chemical and petrochemical standard processes
PMC11-AA1V1FJVXJJ Important Parameters
| Parameter |
Specification |
| Part Number |
PMC11-AA1V1FJVXJJ |
| Product Series |
Cerabar PMC11 |
| Measurement Type |
Gauge Pressure |
| Sensor Technology |
Capacitive, oil-free ceramic diaphragm (99.9% Al₂O₃) |
| Measuring Range |
+400 mbar ... +40 bar (+6 psi ... +600 psi) |
| Overpressure Limit (OPL) |
Max. +60 bar (+900 psi) |
| Max. Working Pressure (MWP) |
+40 bar (+600 psi) |
| Reference Accuracy |
±0.5% of calibrated span |
| Long-term Stability |
±0.2% URL per year |
| Output Signal |
4–20 mA DC |
| Power Supply |
10–30 VDC |
| Process Temperature |
-25 °C to +85 °C (-13 °F to +185 °F) |
| Ambient Temperature |
-25 °C to +85 °C |
| Process Connection |
Threaded (ISO 228 / ASME / DIN 13) |
| Protection Rating |
IP67 |
| Wetted Material |
316L Stainless Steel / 99.9% Alumina Ceramic |
| Weight |
Approx. 0.8 kg |
| Warranty |
5 years |
