6ES7241-1AH32-0XB0 SIEMENS Redundant Power Supply Module 100-240V AC 66 MHz
6ES7241-1AH32-0XB0 Description
The Siemens 6ES7241-1AH32-0XB0 is a 4-channel analog input module designed for the SIMATIC S7-1200 series of programmable logic controllers (PLCs). It provides high-precision voltage and current signal acquisition, enabling the PLC to monitor and process real-world analog variables from sensors and transmitters. The module is ideal for applications requiring reliable measurement of process parameters like temperature, pressure, flow, or level, and features easy configuration through the TIA Portal engineering software. Its compact design and pluggable terminals make it a flexible and efficient solution for industrial automation systems.
6ES7241-1AH32-0XB0 Features
-
4-Channel High-Precision Input: Supports ±10V, 0-10V voltage or 0-20mA, 4-20mA current signals with 13-bit + sign resolution.
-
Flexible Signal Configuration: Each channel can be individually configured for voltage or current input via software (TIA Portal), eliminating the need for hardware jumpers.
-
Wide Input Range: Covers common industrial analog signal standards for versatile application compatibility.
-
Diagnostic Functions: Integrated channel-level diagnostics (e.g., wire break, over/under-range detection) for enhanced system reliability and simplified troubleshooting.
-
Easy Installation: Features a compact form factor with pluggable front connectors for quick wiring and maintenance.
-
Automatic Calibration: On-board calibration ensures long-term measurement accuracy and stability.
-
Seamless TIA Portal Integration: Fully programmable and configurable within Siemens' Totally Integrated Automation Portal for streamlined engineering.
6ES7241-1AH32-0XB0 Material & Applications
-
Material: High-strength polycarbonate housing, flame-retardant thermoplastic connectors, and industrial-grade electronic components with conformal coating for protection against moisture and contaminants.
-
Primary Applications: Process monitoring in water treatment, HVAC control, energy management, packaging machinery, and industrial automation systems requiring analog sensor interfacing.
6ES7241-1AH32-0XB0 Key Parameters
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Voltage: ±10V, 0-10V; Current: 0-20mA, 4-20mA
|
|
|
13 bits + sign (for voltage), 13 bits (for current)
|
|
|
625 µs per channel (all channels: 2.5 ms)
|
|
|
|
|
|
±35V DC (destruction limit)
|
|
|
40 mA (destruction limit)
|
|
|
Channel-to-channel and channel-to-backplane isolation
|
|
|
Wire break, over-range, under-range, parameter assignment error
|
|
|
24V DC (from S7-1200 system)
|
|
|
|
|
|
Removable front connector (screw terminal)
|
|
|
|
|
|
5% to 95% (non-condensing)
|
|
|
|
|
|
|
|
|
CE, UL, cULus, RoHS, REACH
|
