Panasonnic Function Servomotor Drive Kit 400W 3000rpm 1.3NM Control MHMJ042G1U

: Grote Afbeelding : Panasonnic Function Servomotor Drive Kit 400W 3000rpm 1.3NM Control MHMJ042G1U

Productdetails:

Plaats van herkomst:	Japan
Merknaam:	Panasonnic
Modelnummer:	MHMJ042G1U

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	1
Prijs:	Onderhandelbaar
Verpakking Details:	Nieuw in originele doos
Levertijd:	2-3 werkdagen
Betalingscondities:	T/T, Western Union
Levering vermogen:	100

Contact

Gedetailleerde productomschrijving

Merk:	Panasonic	Model:	MHMJ042G1U
Plaats van herkomst:	Japan	Type:	AC -servomotor
Spanning - beoordeeld:	200VAC	RPM:	3000 tpm

Panasonnic Function Servomotor Drive Kit 400W 3000rpm 1.3NM Control MHMJ042G1U

3-Step gain
A 3-step gain switch is available in addition to the normal gain switch.This chooses appropriate gain tunings at both stopping and running. The 3-step gain switch gives you choices of 3 different tunings for normal running, stopping for faster positioning and at stopping. The right gaining tunings achieve lower vibration and quicker positioning time of your application.

Specifications:

Categories Motors, Solenoids, Driver Boards/Modules

Motors - AC, DC

Manufacturer Panasonic Industrial Automation Sales

Series MINAS A5

Part Status Active

Type AC Motor

Function Servomotor

Motor Type -

Voltage - Rated 200VAC

RPM 3000 RPM

Torque - Rated (oz-in / mNm) 184.1 / 1300

Power - Rated 400W

Encoder Type Incremental

Size / Dimension Square - 2.362" x 2.362" (60.00mm x 60.00mm)

Diameter - Shaft 0.551" (14.00mm)

Length - Shaft and Bearing 1.181" (30.00mm)

Mounting Hole Spacing 2.756" (70.00mm)

Termination Style Wire Leads

Features Key, Oil Seal

Gear Reduction Ratio -

Torque - Max Momentary (oz-in / mNm) 538.1 / 3800

Operating Temperature 0°C ~ 40°C

Approvals CE, CSA, cULus, TUV, UL

Weight 3.1 lbs (1.4kg)

Product Details
Panasonic A-Series Motor
Manufacturer: Panasonic
Series: A-Series

Shipping and Order Information
TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
Shipping options vary by location. Call for an accurate quote.
Warranty
The MHMJ042G1U comes with a 1 year warranty.

SIMILAR PRODUCTS

MUMA5AZP1S, MUMA5AZP1T, MUMA012P1S, MUMA012P1T, MUMA022P1S, MUMA022P1T, MUMA042P1S, MUMA042P1T, MHMJ042P1U, MHMD042G1U, MHMJ082P1U, MHMD082G1U, MSME082G1V, MHMJ102P1G, MDME102GCGM, MDME152GCGM, MDME202GCGM, MADHT1505, MADKT1505CA1, MBDJT2207, MADHT1507CA1, MADKT1507CA1, MBDJT2210, MBDHT2510, MBDKT2510CA1, MCDHT3520, MCDKT3520CA1, MCDJT3220, MCDJT3230, MDDHT3530, MDDKT3530CA1, MDDHT5540, MDDKT5540CA1, MEDHT7364, MEDKT7364CA1, MFDHTA390, MFDKTA390CA1, MFDHTB3A2, MFDKTB3A2CA1, MGDHTC3B4, MGDKTC3B4CA1, MHDHTC3B4, MHDKTC3B4CA1 MDME302GCGM, MDME402GCGM, MDME502GCGM

Inertia ratio conversion
You can adjust right inertia ratio by Inertia ratio conversion input (J-SEL) of interface. When you have significant load inertia changes, it can adjust unbalanced speed and position gain turning combination. lt ends up quicker response of your system.

Input/output signal assignment
You can use the parameters to arbitrarily allocate the universal 10 inputs and 6 outputs. (Inputs can be selected as either A contacts or B contacts). The Panaterm setup software provides an exclusive screen for a more simplified setup.

Torque limiter switching
These can be used for applications such as simplified pressure, tension control, and sensor-less homing.
