Manufacturer: | Mitsubishi Electric | Model: | QD77MS4 |
---|---|---|---|
Product type: | MELSEC-Q QD77MS Simple Motion Module | Country of origin: | Japan |
Number of control axes: | 4 axes | Operation cycle: | 0.88ms/1.77ms |
lash ROM write count Max: | 100000 times | Shipping weight: | 1.5 Kg |
Markeren: | modicon quantumbewerker,quantumeenheidsbewerker |
MELSEC-Q QD77MS Simple Motion Module Modicon Quantum PLC Mitsubishi
De QD77M4 is een hoogwaardige Mitsubishi Electric motion controller module ontworpen voor precieze multi-as positioneringscontrole in industriële automatiseringssystemen. Het integreert naadloos met Mitsubishi’s MELSEC iQ-R Series PLC's, en biedt geavanceerde motion control mogelijkheden, snelle respons en flexibele synchronisatie voor complexe machines. Ideaal voor toepassingen die nauwkeurigheid, herhaalbaarheid en betrouwbaarheid vereisen, ondersteunt de QD77M4 tot 4 assen van servobesturing met real-time monitoring en diagnostiek.
Merk: Mitsubishi Electric
Model: QD77M4
Type: Motion Controller Module (voor MELSEC iQ-R Series)
Besturingsassen: 4 assen (gelijktijdige besturing)
Communicatie-interface: SSCNET III/H (high-speed glasvezelnetwerk)
Compatibele servoaandrijvingen: Mitsubishi MR-J4 serie
Programmeersoftware: GX Works3 (motion control configuratie)
Montage: DIN-rail of directe paneelmontage
Behuizing: Vlamvertragend plastic (UL94 V-0 compliant)
Aansluitingen: Vergulde contacten voor corrosiebestendigheid
Koelmethode: Natuurlijke convectie (ventilatorloos ontwerp)
Beschermingsklasse: IP20 (binnengebruik, stofgevoelig)
CNC-machines
Robotica & pick-and-place systemen
Verpakkingsmachines
Halfgeleiderfabricage
Druk- en textielapparatuur
Parameter |
Specificatie |
Eenheid/Opmerkingen |
---|---|---|
Besturingsmethode | SSCNET III/H | Glasvezelcommunicatie |
Aantal assen | 4 | Onafhankelijke/gesynchroniseerde besturing |
Positioneringsnauwkeurigheid | ±1 puls of beter | Afhankelijk van servoresolutie |
Maximumsnelheid | 10.000.000 pulsen/sec (per as) | Varieert per servomotor |
I/O-punten | 32 ingangen / 32 uitgangen (configureerbaar) | Digitale signalen |
Voeding | 24V DC (±10%) | 0.8A typisch verbruik |
Bedrijfstemperatuur | 0°C tot +55°C | Opslag: -25°C tot +75°C |
Trillingsbestendigheid | 5.9 m/s² (10–55 Hz) | JIS B 3502 compliant |
Certificeringen | CE, UL, cUL, RoHS | Industriële standaarden |
Opmerking: Raadpleeg voor gedetailleerde bedradingsschema's en programmeerinstructies de Mitsubishi QD77M4 Gebruiker
